Rapid Deployment Telescopic Belt Conveyor Improved Ergonomics Energy Efficiency
The Realkey telescopic belt conveyor (RKLOAD-TBC), often referred to as an extendable or retractable belt conveyor, is an advanced solution designed for efficient loading and unloading operations. Its construction consists of fixed segments, multiple extendable sections, robust support frames, and sophisticated control systems. This conveyor not only allows for length adjustments within specified parameters but can also integrate a hydraulic system for angle modifications, enabling effective bidirectional operation during loading and unloading processes.
The extendable sections of the RKLOAD-TBC can reach deep into a vehicle's cargo space, significantly reducing the distance goods need to be manually handled. This functionality enhances the loading and unloading workflow, cuts down on handling time, reduces physical strain on workers, minimizes the risk of product damage, and lowers overall costs associated with loading and unloading, thereby increasing productivity. The RKLOAD-TBC is widely utilized across various industries, including postal services, express delivery, food processing, tobacco, pharmaceuticals, and consumer goods.
For additional information regarding the Realkey telescopic belt conveyor (RKLOAD-TBC), please refer to the detailed product description below or contact Realkey’s customer service.
Technical Parameters
| Model | Sections | Fixed Section Length(mm) | Extended Section Length(mm) | Total Length(mm) | characteristic |
| TBC2-5+3 | Two | 5000 | 3000 | 8000 | |
| TBC2-7+5 | 7000 | 5000 | 12000 | Belt Width (mm)::400/600/800/900/1000 | |
| TBC3-5+6 | Three | 5000 | 6000 | 11000 | Belt Material: PVC/PVK/Composite Belt |
| TBC3-6+8 | 6000 | 8000 | 14000 | Operating Speed: 0.2~0.6 (m/s) | |
| TBC3-7+9.5 | 7000 | 9500 | 16500 | Maximum Load: 60 (kg/m^2) | |
| TBC4-4+6 | Four | 4000 | 6000 | 10000 | Ambient Temperature: -20~40 (℃) |
| TBC4-5+9 | 5000 | 9000 | 14000 | Ambient Voltage: Three-phase five-wire 380V | |
| TBC4-6+12 | 6000 | 12000 | 18000 | Hydraulic Lift: Optional | |
| TBC4-7+14 | 7000 | 14000 | 21000 | OEM/ODM: Customized design and manufacturing according to customer requirements are supported. | |
| TBC5-6+14 | Five | 6000 | 14000 | 20000 | |
| TBC5-7+17 | 7000 | 17000 | 24000 |
Product Features
Cost Efficiency and Enhanced Productivity
The RKLOAD-TBC streamlines the loading and unloading process compared to traditional methods, significantly reducing labor intensity and cutting loading times by up to 50%.
Safe and Smooth Handling
By reducing the frequency of handling goods, the RKLOAD-TBC effectively decreases product damage and associated losses.
User-Friendly Operation
Featuring an easy-to-use interface, it allows for straightforward control of the telescopic functions and conveyor speed, thereby minimizing training costs for operators.
Simple Maintenance
With its innovative technology and modular design, the RKLOAD-TBC is easy to maintain and designed for a long operational lifespan.
Application
The RKLOAD-TBC has demonstrated significant value across multiple sectors due to its adaptability and efficiency, making it essential for improving material handling and operational workflows.
Loading and Unloading Zones
Ideal for the rapid transfer of goods between trucks and storage facilities, greatly enhancing operational efficiency.
Warehouse Operations
Effective for short-distance material transport within warehouses, alleviating physical demands on personnel.
Logistics Hubs
Integrates well with automated sorting systems for quick and efficient package movement and distribution.
Postal Services
Facilitates the swift handling and sorting of letters and parcels within postal operations.
Food Industry
Ideal for the hygienic transport of both raw ingredients and finished products in food processing environments.
Advantages
Versatile Options
Realkey offers a diverse range of models, including fixed, track-based, and free-moving conveyors, with configurations from two-section to five-section designs to meet varied user needs.
Safety Prioritization
Realkey conveyor systems are designed with operator safety in mind, featuring multiple protective devices.
Tailored Solutions
Realkey provides customized design and manufacturing services to accommodate specific customer requirements.
Proven Reliability
With 17 years of experience in the logistics conveying field, Realkey products are known for their robustness and dependability. When seeking solutions in logistics conveying and sorting, Realkey is a trusted partner you can rely on.
|
|
